Designed for the long-haul truckload carrier and owner operators,
the Great Dane PRESTIGE SERIES refrigerated trailer is renowned for its
light weight, structural integrity, and consistently high resale value. From
its proven panel foaming technology to the highly detailed production process,
the PRESTIGE offers quality beyond question.
Stainless-steel front bottom rail fully wraps the nose, providing total lower front protection against corrosion and impact damage.
Stainless-steel front corners and pre-painted corrugated side panels offer exceptional strength and appearance.
Great Dane's innovative, void-free foaming process assures superior lining adhesion and flat, smooth walls.
ThermoGuard interior lining efficiently maintains cooling capacity while reducing unit run-time, fuel consumption, and weight gain.
Long Life Floor System features heavy-duty, 16,000 lb. rated aluminum duct floor.
Hendrickson ULTRAA-K Sliding Suspension combines light weight with durability and Zero Maintenance Damping Technology, which eliminates the need for shock absorbers while being nearly 100 lbs. lighter.
Bridgestone R-123 SmartWay verified tires and aluminum wheels.
Stainless-steel rear frame is engineered for maximum strength and light weight.
Stainless-steel buck plate has three-inch, full width bumper channel and rubber dock bumpers to reduce impact damage.
Stainless-steel diamond pattern rear swing doors feature internal lateral braces for optimal reinforcement and durability along with triple gasket seals to eliminate moisture intrusion and lock in cold air.
Grote all-LED maintenance free Long-Life System.
The Great Dane PRESTIGE SERIES, exclusively offered by Jim Hawk Truck Trailers. The highest performing, most thermally efficient trailer available.
Product
Product
ESS - Everest Super Seal Reefer
Manufacturing
Plant Wayne, NE
Model Year
2020
Geometric Dimensions
Packaged Options
None
Serial Plate
U.S.Certification Plate
Overall Height
13' 6"
Overall Length
53' 0"
Overall Width
102.36"
Upper Coupler Height
48"
Kingpin Location
24.00"
Landing Gear Location
105.0'' From Kingpin
Wedge
No Wedge
Undercarriage Design
Tandem Axle, Slide Air-Ride Suspension, 121" Axle Centers
